Name: Gravel Disc Fork
Brand: ENVE Composites
SKU: 200-2006-003
Price: 575.0 USD
Availability: InStock

$575.00

A purpose built carbon fiber fork for gravel and cyclocross bikes featuring internal hose routing, flat mount brake compatibility and clearance for up to 50mm tires.

Rake

47mm

50mm

In stock, ready to ship
Inventory on the way

Product Locator by Locally

[{"id":45111161520412,"title":"47mm","option1":"47mm","option2":null,"option3":null,"sku":"200-2006-003","requires_shipping":true,"taxable":true,"featured_image":{"id":41124174364956,"product_id":8267117527324,"position":1,"created_at":"2023-05-10T11:59:17-06:00","updated_at":"2023-05-10T11:59:17-06:00","alt":null,"width":1800,"height":1200,"src":"\/\/enve.com\/cdn\/shop\/products\/ENVE_IM_180724_8944.jpg?v=1683741557","variant_ids":[45111161520412,45111161553180]},"available":true,"name":"Gravel Disc Fork - 47mm","public_title":"47mm","options":["47mm"],"price":57500,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"00818801027665","featured_media":{"alt":null,"id":33477465342236,"position":1,"preview_image":{"aspect_ratio":1.5,"height":1200,"width":1800,"src":"\/\/enve.com\/cdn\/shop\/products\/ENVE_IM_180724_8944.jpg?v=1683741557"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":45111161553180,"title":"50mm","option1":"50mm","option2":null,"option3":null,"sku":"200-2006-004","requires_shipping":true,"taxable":true,"featured_image":{"id":41124174364956,"product_id":8267117527324,"position":1,"created_at":"2023-05-10T11:59:17-06:00","updated_at":"2023-05-10T11:59:17-06:00","alt":null,"width":1800,"height":1200,"src":"\/\/enve.com\/cdn\/shop\/products\/ENVE_IM_180724_8944.jpg?v=1683741557","variant_ids":[45111161520412,45111161553180]},"available":true,"name":"Gravel Disc Fork - 50mm","public_title":"50mm","options":["50mm"],"price":57500,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"00818801027672","featured_media":{"alt":null,"id":33477465342236,"position":1,"preview_image":{"aspect_ratio":1.5,"height":1200,"width":1800,"src":"\/\/enve.com\/cdn\/shop\/products\/ENVE_IM_180724_8944.jpg?v=1683741557"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

A purpose built carbon fiber fork for gravel and cyclocross applications featuring internal hose routing, flat mount brake compatibility, and clearance for up to 50mm tires.

As gravel riders and partners of the custom frame builder community, we were able to identify the technical improvements needed in a full-carbon gravel fork to meet the needs of the modern gravel rider and the bicycle frames they are riding. As the industry’s leading fork manufacturers, we deliver a new gravel standard for compliance, weight savings, strength, and reliability for demanding rides over any surface.

Gravel riders looking for more clearance, weight savings, compliance and the versatility of fender mounts will enhance their gravel grinding experience with this fork.


Material	Carbon
Weight	520g
Steer Tube Length	350mm
Steer Tube Taper	1.125" to 1.5"
Rake	47mm & 50mm
Axle To Crown	395mm
Brake	Disc
Axle Compatibility	12mm Thru
Max Rotor Size	140mm - 160mm
Max Tire Clearance	700c x 50c, 27.5" x 2.25"
Torque Spec – Steer Tube	5.5nm
Torque Spec - Axle	8nm
Product SKU	47: 200-2006-003 50: 200-2006-004

*Steer tube not compatible with star nuts, please use a compression plug
